AWM UL 2586 18/5 105C 600V – WHITE


Voltage Rating


Conductor Count


Conductor Stranding

Maximum Temperature Rating


Bulk Quantity Discount

SKU: C2586O18-5S-B01 Categories: , ,


AWM UL 2586 18/5 105C 600V - WHITE
AWM UL 2586 18/5 105C 600V - WHITE $0.37

40000 in stock


National Electric USA‘s quality AWM UL 2586 18/5 105C 600V – WHITE cable are a part of the portable cord product line. Our wide range of AWM UL 2586 18/5 105C 600V – WHITE cable can be seen used throughout a large number of industries such as but not limited to the access control, appliance, automotive & transportation, AV, earth moving, construction, agricultural, electronics, energy, environmental, factory automation & robotics, heating, ventilation, air conditioning, lighting, maritime, watercraft, medical, pool, spa, hot tub, residential, commercial, sporting goods, telecom, gas grill, stove, and many other industry applications.. At National Electric USA, we stock and can procure several cable variations and options that may interest you.

Subj.758 Section 2 Page 2586 Issued:1972-02-14
Style 2586 Multiple-conductor cable using non-integral jacket


Rating 105 deg C, 600 or 1000 Vac, Cable flame.
Conductor 40 AWG minimum.
Insulated Conductor Labeled or complying with manufacturer’s AWM Procedure.
Assembly Two or more conductors or groups of conductors laid parallel or twisted forming a flat, oval or round cable. The lay of the conductors is not specified. A barrier layer and/or fillers are optional. May use same or mixed AWG size.
Covering Optional, Extruded PVC, 6 mils minimum thickness at any point.
Shield Optional.
Jacket Extruded PVC.
Diameter of cable under jacket* Minimum average thickness Minimum thickness at any point
0.700 inch or less 30 mils 24 mils
0.701-1.000 inch 60 mils 48 mils
1.001-1.501 inch 80 mils 64 mils
1.501-2.500 inch 110 mils 88 mils
* – Major diameter if cable is flat or oval
Standard Appliance Wiring Material UL 758.
Marking General.
Use External interconnection or internal wiring.

UL and the UL Logo are trademarks of UL LLC © 2022

Manufacturer Spec Data: UL Product Page
